Terminals:
free wires
litz wires
flat copper connectors
ring cable lugs
customer specified plugs
block terminals
|
|
|
Table
|
|
|
Type
|
Type size
|
Sec
power
|
Efficiency
|
Dimensions in mm
|
Mounting holes
|
Copper
weight
|
Total
weight
|
|
b
|
l
|
l1
|
h
|
h1
|
f1
|
f2
|
f3
|
|
TUO
|
UI 150/36 S
|
1500 VA
|
95 %
|
202
|
92
|
108
|
261
|
311
|
78
|
124
|
10
|
5,5 kg
|
15 kg
|
|
TUO
|
UI 150/52 S
|
2000 VA
|
96 %
|
202
|
108
|
124
|
261
|
311
|
94
|
124
|
10
|
5,4 kg
|
19 kg
|
|
TUO
|
UI 150/65 S
|
2500 VA
|
96 %
|
202
|
121
|
137
|
261
|
311
|
107
|
124
|
10
|
6,0 kg
|
23 kg
|
|
TUO
|
UI 150/77 S
|
3000 VA
|
96 %
|
202
|
133
|
149
|
261
|
311
|
119
|
124
|
10
|
6,5 kg
|
26 kg
|
|
TUO
|
UI 150/92 S
|
3400 VA
|
96 %
|
202
|
148
|
165
|
261
|
311
|
134
|
124
|
10
|
7,5 kg
|
30 kg
|
|
TUO
|
UI 150/103 S
|
3800 VA
|
97 %
|
202
|
160
|
176
|
261
|
311
|
145
|
124
|
10
|
7,2 kg
|
33 kg
|
|
TUO
|
UI 168/58 S
|
3000 VA
|
96 %
|
226
|
124
|
141
|
288
|
338
|
110
|
136
|
10
|
7,7 kg
|
26 kg
|
|
TUO
|
UI 168/75 S
|
3800 VA
|
97 %
|
226
|
141
|
158
|
288
|
338
|
127
|
136
|
10
|
8,0 kg
|
32 kg
|
|
TUO
|
UI 168/92 S
|
4500 VA
|
97 %
|
226
|
160
|
175
|
288
|
338
|
144
|
136
|
10
|
10,3 kg
|
40 kg
|
|
TUO
|
UI 180/63 S
|
3900 VA
|
97 %
|
242
|
136
|
156
|
306
|
355
|
125
|
144
|
10
|
9,8 kg
|
33,6 kg
|
|
TUO
|
UI 180/78 S
|
4600 VA
|
97 %
|
242
|
153
|
172
|
306
|
355
|
140
|
144
|
10
|
11 kg
|
40 kg
|
|
TUO
|
UI 180/93 S
|
5600 VA
|
97 %
|
242
|
168
|
187
|
306
|
355
|
155
|
144
|
10
|
11 kg
|
45 kg
|
|
TUO
|
UI 210/53 S
|
5600 VA
|
97 %
|
282
|
136
|
158
|
362
|
420
|
123
|
176
|
12
|
14 kg
|
42 kg
|
|
TUO
|
UI 210/63 S
|
6500 VA
|
97 %
|
282
|
146
|
167
|
362
|
420
|
133
|
176
|
12
|
16 kg
|
49 kg
|
|
TUO
|
UI 210/73 S
|
7000 VA
|
97 %
|
282
|
156
|
177
|
362
|
420
|
143
|
176
|
12
|
18 kg
|
55 kg
|
|
TUO
|
UI 210/88 S
|
8400 VA
|
97 %
|
282
|
173
|
191
|
362
|
420
|
158
|
176
|
12
|
25 kg
|
70 kg
|
|
TUO
|
UI 210/103 S
|
9800 VA
|
98 %
|
282
|
186
|
193
|
362
|
420
|
173
|
176
|
12
|
22 kg
|
74 kg
|
|
TUO
|
UI 210/133 S
|
12,8 kVA
|
98 %
|
282
|
220
|
236
|
362
|
420
|
203
|
176
|
12
|
26 kg
|
93 kg
|
|
TUO
|
UI 240/83 S
|
10,8 kVA
|
98 %
|
322
|
190
|
197
|
412
|
470
|
157
|
196
|
15
|
23 kg
|
80 kg
|
|
TUO
|
UI 240/110 S
|
13,8 kVA
|
98 %
|
322
|
218
|
225
|
412
|
470
|
184
|
196
|
15
|
27 kg
|
100 kg
|
|
TUO
|
UI 240/140 S
|
16 kVA
|
98 %
|
322
|
248
|
255
|
412
|
470
|
214
|
196
|
15
|
39 kg
|
132 kg
|
|
TUO
|
UI 300/100 S
|
25 kVA
|
98 %
|
385
|
195
|
245
|
505
|
620
|
195
|
200
|
15
|
64 kg
|
154 kg
|
|
TUO
|
UI 300/125 S
|
35 kVA
|
98 %
|
385
|
220
|
270
|
505
|
620
|
220
|
200
|
15
|
80 kg
|
190 kg
|
|
TUO
|
UI 300/150 S
|
45 kVA
|
98 %
|
385
|
245
|
295
|
505
|
620
|
245
|
200
|
15
|
82 kg
|
230 kg
|
|
TUO
|
UI 300/175 S
|
55 kVA
|
98 %
|
385
|
270
|
320
|
505
|
620
|
270
|
200
|
15
|
95 kg
|
260 kg
|
|
TUO
|
UI 300/200 S
|
65 kVA
|
98 %
|
385
|
295
|
345
|
505
|
620
|
295
|
200
|
15
|
117 kg
|
300 kg
|
|
TUO
|
UI 360/150 S
|
75 kVA
|
98 %
|
445
|
245
|
305
|
620
|
-
|
255
|
310
|
15
|
150 kg
|
350 kg
|
|
TUO
|
UI 360/200 S
|
85 kVA
|
98 %
|
445
|
295
|
355
|
620
|
-
|
305
|
310
|
15
|
160 kg
|
400 kg
|
|
TUO
|
UI 420/200 S
|
130 kVA
|
98 %
|
560
|
330
|
390
|
700
|
-
|
-
|
-
|
15
|
270 kg
|
600 kg
|
|
Technical changes and optimisation reserved. All details are guide values, variations are possible.
|
10/2012
|
|
|
|
Examples
|
|
|
Type
|
Type size
|
Sec
power
|
Dimensions in mm
|
Mounting holes
|
Copper
weight
|
Total
weight
|
BV
|
|
b
|
l
|
l1
|
h
|
h1
|
f1
|
f2
|
f3
|
|
TUO
|
UI 240/140
|
23 kVA
|
320
|
260
|
-
|
-
|
490
|
-
|
-
|
-
|
46,5 kg
|
140 kg
|
3817000
|
|
Technical changes and optimisation reserved. All details are guide values, variations are possible.
|
12/2021
|
|
|
|
