Autotransformer 110/230V 230/110V
240VA up to 1000VA
|
|
Autotransformers conform to EN61558-2-13 up to 110V up to 230V (230V up to 110V) and a power of 240 VA up to 1000 VA
Datasheet as PDF
|
|
|
|
|
|
|
|
|
|
|
EI120
|
|
|
|
EI96
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Field of application
|
|
Autotransformers enable the working of 230 V (110 V) units at 110 V (230 V) networks.
|
|
|
|
|
|
|
|
|
|
|
|
Description
|
|
Autotransformers in solid construction, completely potted under vaccum with highly insulating polyurethane cst resin. The windings are connected to each other, no galvanic separation.
Isolation housing with handles.
These transformers have twice the power of an isolation transformer with the same size.
For critical circuits, the phase of the net connection against earth has to be tested, when using an autotransformer 230 V -> 110 V.
Special types
- other primary- or secondary-voltages
- three phase type
|
|
|
|
|
|
|
|
|
|
|
|
Table
|
|
Type
|
Type size
|
Sec.-
power
|
Votlage
pri
|
Voltage
sec
|
Dimensions
|
Copper-
weight
|
Total-
weight
|
|
ATU 240
|
EI 96/35,7
|
240
|
VA
|
110
|
V
|
230
|
V
|
Zeichnung/drawing EI 96
|
475
|
g
|
2,4
|
kg
|
|
ATU 280
|
EI 96/35,7
|
280
|
VA
|
110
|
V
|
230
|
V
|
Zeichnung/drawing EI 96
|
475
|
g
|
2,4
|
kg
|
|
ATU 320
|
EI 96/45,7
|
320
|
VA
|
110
|
V
|
230
|
V
|
Zeichnung/drawing EI 96
|
570
|
g
|
3,0
|
kg
|
|
ATU 360
|
EI 96/45,7
|
360
|
VA
|
110
|
V
|
230
|
V
|
Zeichnung/drawing EI 96
|
570
|
g
|
3,0
|
kg
|
|
ATU 400
|
EI 96/59,7
|
400
|
VA
|
110
|
V
|
230
|
V
|
Zeichnung/drawing EI 96
|
600
|
g
|
3,6
|
kg
|
|
ATU 500
|
EI 96/59,7
|
500
|
VA
|
110
|
V
|
230
|
V
|
Zeichnung/drawing EI 96
|
600
|
g
|
3,6
|
kg
|
|
ATU 600
|
EI 120/53
|
600
|
VA
|
110
|
V
|
230
|
V
|
Zeichnung/drawing EI120
|
970
|
g
|
5,5
|
kg
|
|
ATU 700
|
EI 120/53
|
700
|
VA
|
110
|
V
|
230
|
V
|
Zeichnung/drawing EI120
|
970
|
g
|
5,5
|
kg
|
|
ATU 800
|
EI 120/73
|
800
|
VA
|
110
|
V
|
230
|
V
|
Zeichnung/drawing EI120
|
1200
|
g
|
6,9
|
kg
|
|
ATU1000
|
EI 120/73
|
1000
|
VA
|
110
|
V
|
230
|
V
|
Zeichnung/drawing EI120
|
1200
|
g
|
6,9
|
kg
|
|
|
|
ATE 240
|
EI 96/35,7
|
240
|
VA
|
230
|
V
|
110
|
V
|
Zeichnung/drawing EI 96
|
475
|
g
|
2,4
|
kg
|
|
ATE 280
|
EI 96/35,7
|
280
|
VA
|
230
|
V
|
110
|
V
|
Zeichnung/drawing EI 96
|
475
|
g
|
2,4
|
kg
|
|
ATE 320
|
EI 96/45,7
|
320
|
VA
|
230
|
V
|
110
|
V
|
Zeichnung/drawing EI 96
|
570
|
g
|
3,0
|
kg
|
|
ATE 360
|
EI 96/45,7
|
360
|
VA
|
230
|
V
|
110
|
V
|
Zeichnung/drawing EI 96
|
570
|
g
|
3,0
|
kg
|
|
ATE 400
|
EI 96/59,7
|
400
|
VA
|
230
|
V
|
110
|
V
|
Zeichnung/drawing EI 96
|
600
|
g
|
3,6
|
kg
|
|
ATE 500
|
EI 96/59,7
|
500
|
VA
|
230
|
V
|
110
|
V
|
Zeichnung/drawing EI 96
|
600
|
g
|
3,6
|
kg
|
|
ATE 600
|
EI 120/53
|
600
|
VA
|
230
|
V
|
110
|
V
|
Zeichnung/drawing EI120
|
970
|
g
|
5,5
|
kg
|
|
ATE 700
|
EI 120/53
|
700
|
VA
|
230
|
V
|
110
|
V
|
Zeichnung/drawing EI120
|
970
|
g
|
5,5
|
kg
|
|
ATE 800
|
EI 120/73
|
800
|
VA
|
230
|
V
|
110
|
V
|
Zeichnung/drawing EI120
|
1200
|
g
|
6,9
|
kg
|
|
ATE1000
|
EI 120/73
|
1000
|
VA
|
230
|
V
|
110
|
V
|
Zeichnung/drawing EI120
|
1200
|
g
|
6,9
|
kg
|
|
technical changes and optimization reserved
|
01/2010
|
|
|
|
|
|
|
|
|
