Transformer for airplane board nets 40 VA to 920 VA
|
|
One-phase transformer 400 Hz
Application
Avionics and ship board nets
|
|
|
|
Datasheet as PDF
|
|
|
|
|
|
Technical data
|
|
Performance: 1 AC isolating transformer conform to IEC/EN 61558 2-4-6/VDE 0570-2-4-6
Temperature class: B (130°C)
max. ambient temperature: 40°C
Fire class: UL94V0
Protection index: open transformer - IP00, prepared for index I, impregnated under vacuum
Frequency: 400 Hz
Cooling: Self cooling
Mounting: with mounting angles
|
|
|
|
Alternative version
|
|
Terminals
|
|
Free wires
Stranded, flexible wires with conductor-end-tube
Flat-plug-tubes 2,8 - 4,8 - 6,3 mm
Round plug
Ring cable eye
Customer specified plugs
|
|
Insertion for print mounting or with flat sockets 2,8 - 4,8 - 6,3 mm is possible
|
|
Bobbins are also available as PCB construction
|
|
|
|
Table
|
|
Type
|
Type size
|
Sec.-
power
|
Efficiency
|
Dimensions
|
Number of pins
|
Mounting holes
|
Copper-
weight
|
Total
weight
|
|
b1
|
b
|
l
|
h
|
f1
|
f2
|
f3
|
|
|
|
TMO
|
SM 42
|
40 VA
|
91 %
|
54,0
|
50
|
42
|
51
|
2 x 4
|
32
|
32
|
3,6
|
55 g
|
0,20 kg
|
|
TMO
|
SM 55
|
120 VA
|
94 %
|
67,2
|
64
|
49
|
66
|
2 x 5
|
38
|
44
|
3,6
|
115 g
|
0,45 kg
|
|
TMO
|
SM 65
|
215 VA
|
95 %
|
77,6
|
73
|
59
|
75
|
2 x 6
|
47
|
50
|
4,8
|
215 g
|
0,85 kg
|
|
TMO
|
SM 74
|
360 VA
|
96 %
|
87,1
|
83
|
68
|
85
|
2 x 7
|
52
|
56
|
4,8
|
350 g
|
1,30 kg
|
|
TMO
|
SM 85a
|
440 VA
|
96 %
|
97,6
|
93
|
66
|
95
|
2 x 8
|
52
|
64
|
4,8
|
370 g
|
1,70 kg
|
|
TMO
|
SM 85b
|
560 VA
|
96 %
|
100,0
|
93
|
80
|
95
|
2 x 8
|
64
|
64
|
4,8
|
400 g
|
2,30 kg
|
|
TMO
|
SM 102a
|
730 VA
|
97 %
|
117,7
|
111
|
78
|
113
|
2 x 9
|
62
|
84
|
5,8
|
720 g
|
2,90 kg
|
|
TMO
|
SM 102b
|
920 VA
|
97 %
|
117,7
|
111
|
95
|
113
|
2 x 9
|
79
|
84
|
5,8
|
810 g
|
4,00 kg
|
|
Technical changes and optimization reserved
|
01/2010
|
|
|
|
|
|
