One-phase high-current transformer up to 10000 A
|
|
Datasheet as PDF
|
|
|
|
|
|
|
|
|
Field of application
|
|
Welding transformer, styrofoam cutter, test transformer
|
|
|
|
Technical data
|
|
1AC-transformer
Frequency: 50 Hz
Construction: open
|
|
|
|
Table
|
|
Type
|
Type size
|
Sec.-
power
|
Current
|
Dimensions without copper terminals
in mm
|
Mounting holes
|
Copper-
weight
|
Total
weight
|
BV
|
|
b
|
l
|
l1
|
h
|
h1
|
f1
|
f2
|
f3
|
|
TEOFAN
|
EI 84/29,5
|
160 VA
|
65-80 A
|
84
|
70
|
-
|
70
|
-
|
56
|
70
|
4,5
|
0,31 kg
|
1,5 kg
|
3235001
|
|
TUO.WR
|
UI 120/51
|
1000 VA
|
800 A
|
162
|
97
|
107
|
209
|
260
|
79
|
100
|
7
|
4,5 kg
|
12,8 kg
|
19052001
|
|
TUOKWR
|
UI 120/51
|
1000 VA
|
100 A
|
162
|
97
|
107
|
209
|
260
|
79
|
100
|
7
|
4,5 kg
|
12,8 kg
|
24043001
|
|
TUO.WR
|
UI 120/61
|
700 VA
|
1000 A
|
162
|
107
|
117
|
209
|
260
|
89
|
100
|
7
|
4,6 kg
|
12,9 kg
|
16028001
|
|
TUO.WR
|
UI 150/77
|
2500 VA
|
500 A
|
202
|
133
|
149
|
261
|
311
|
119
|
124
|
10
|
9,1 kg
|
29 kg
|
3339003
|
|
TUO.WR
|
UI 150/77
|
3000 VA
|
1000 A
|
202
|
133
|
149
|
261
|
311
|
119
|
124
|
10
|
10 kg
|
30 kg
|
12029002
|
|
TUO.WR
|
UI 150/77
|
3000 VA
|
2500 A
|
202
|
133
|
149
|
261
|
311
|
119
|
124
|
10
|
10 kg
|
30 kg
|
3339001
|
|
TUOKWR
|
UI 168/92
|
5000 VA
|
2500 A
|
223
|
180
|
-
|
299
|
353
|
144
|
136
|
10
|
15,3 kg
|
42 kg
|
11050001
|
|
TUO.WR
|
UI 240/110
|
10000 VA
|
1000 A
|
322
|
218
|
225
|
412
|
470
|
184
|
196
|
15
|
-
|
82 kg
|
1977001
|
|
TUODWR
|
UI 300/150
|
35000 VA
|
850 A
|
400
|
220
|
-
|
520
|
-
|
-
|
-
|
-
|
60,0 kg
|
140,0 kg
|
-
|
|
TUODWR
|
UI 360/150
|
42000 VA
|
850 A
|
448
|
320
|
-
|
665
|
-
|
-
|
-
|
-
|
65,0 kg
|
240,0 kg
|
-
|
|
Technical changes and optimization reserved
|
01/2011
|
|
|
|
|
|
