One-phase high current choke 500 A 640 µH


Datasheet as PDF

cesymb_harmonicsclass_Henergysymb-RoHs


One-phase high current choke

BV 19014003


Technical data


Inductance: L = 640 µH
Direct current: IDC = 300 A eff
Alternating current: IAC = 300 A ss
Frequency: f = 300 Hz
Weight: G = 310 kg
Winding: thin copper sheets
Core: rib plates with several air gaps on each limb
Cooling: AN (natural) without ventilation
Saturation consolidation: up to 1000 A
