One-phase power-HF choke UI 93 and UU 93
|
|
|
|
Da
|
|
|
 BV 2983041 Bolt terminals
|
|
|
tasheet as PDF |
|
|
|
Description
|
|
Performance
|
Switch-mode power supply choke conform toEN 61558, EN 50081-1 and -2
EN 50082-1 and -2
high frequency power choke
HF-choke, ferrite choke and for power application
|
|
Application
|
Suitable as HF-choke for power application
e.g. in inverters for railway applications
a construction as HF-transformer is possible as well
|
|
Voltages
|
to customer’s specification
|
|
Frequency
|
20 kHz up to 300 kHz
|
|
Core material
|
N87 or PL7 for high power, with other materials it’s less power
|
|
Temperature class
|
F (155°C) if varnished, B (130°C) if potted
|
|
Temperature
|
Ambient 40°C, higher temperatuers decrease the energy
|
|
Protective class
|
Fire class UL94 V0, IP 00 conform to DIN 40 050
|
|
Winding
|
with lacquered copper wire, Hf-litz wire, foil or triple insualted Furukawa wire
|
|
Construction
|
Vacuum varnished (open version), impregnated with class H varnish
or vacuum potted in a housing
|
|
Terminals
|
free wires, connectors or sockets
|
|
Safety
|
Margins to redeem air- and creepage distances
|
|
|
|
|
|
Table
|
|
Type
|
Type size
|
Energy
0,5 x L x I2
|
Dimensios in mm
|
Copper-
weight
|
Total
weight
|
|
l
|
b
|
h
|
|
DUO
|
UI 93/104/16
|
80
|
130
|
104
|
50
|
0,6 kg
|
1,3 kg
|
|
DUO
|
UI 93/104/30
|
150
|
130
|
104
|
65
|
0,7 kg
|
1,8 kg
|
|
DUO
|
UI 93/152/16
|
105
|
130
|
152
|
50
|
0,9 kg
|
2,0 kg
|
|
DUO
|
UI 93/152/30
|
200
|
130
|
152
|
65
|
1,1 kg
|
2,6 kg
|
|
DUO
|
UI 93/152/60
|
400
|
130
|
152
|
95
|
1,8 kg
|
4,8 kg
|
|
DUO
|
UI 93/152/90
|
600
|
130
|
152
|
125
|
2,3 kg
|
6,8 kg
|
|
DUO
|
UI 93/152/120
|
800
|
130
|
152
|
155
|
3,0 kg
|
9,0 kg
|
|
DUO
|
UI 93/152/150
|
1000
|
130
|
152
|
185
|
3,9 kg
|
11,4 kg
|
|
Technical changes and optimization reserved
|
01/2010
|
|
The energy is calculated with 50 kHz, these values are examples and can differ depending on use.
|
|
|
|
|
|
